Item Qty Ref. Value Package Description Manuf. Part number

82 1 U500 L7986ATR HSOP8

38V, 3 A step-down switching

regulator

ST L7986ATR

83 1 Y200 N.A. L2.0_W1.6 Not populated SMD crystal N.A. N.A.

84 1

Solder

TP400-

TP401

MP-A2 Coil, MP-A2

WURTH

ELEKTRONIK

760308103102

85 7

R100,

R103,

R205,

R238,

R401,

R402,

R406

N.A. 0402 Not populated resistor SMD 0402 N.A. N.A.

86 2

C200,

C239

N.A. 0603 Not populated capacitor SMD 0603 N.A. N.A.

87 5

C312,

C406,

C413,

C414,

C416

N.A. 0402 Not populated capacitor SMD 0402 N.A. N.A.

UM3231

STEVAL-WBC2TX50 description

UM3231 - Rev 1

page 53/84
