Pin
number
Pin name
On‑board
peripheral signals
ARDUINO
®
signals
STMod+ signals
A11 PE13 - D6-TIM1_CH3 -
B11 PE14 - D9-TIM1_CH4 -
A12 PE15 - D13-SPI5_SCK P4-SPI5_SCK
R3 PF0 ETH_GTX_CLK - -
P4 PF1 - - P18-GPIO
N4 PF2 ETH_CLK125 - -
M2 PF3 -
A4-ADC1 INP16
(1)
-
L2 PF4 EXT_SMPS_MODE - -
M3 PF5 ETH_CLK - -
L5 PF6 - D0-USART2RX P3-USART2_RX
M1 PF7 ETH_RX_CLK - -
N3 PF8 ETH_RXD2 - -
P1 PF9 ETH_RXD3 - -
L4 PF10 ETH_RX_DV - -
P3 PF11 ETH_TX_EN - -
T1 PF12 ETH_TXD0 - -
R2 PF13 ETH_TXD1 - -
N2 PF14 ETH_RXD0 - -
N1 PF15 ETH_RXD1 - -
R13 PG0 LCD_R0 - -
R9 PG1 LCD_G1 - -
T11 PG2 - D11‑TIM14_CH1/SPI5_MOSI P2-SPI5_MOSI
R1 PG3 ETH_TXD2 - -
P2 PG4 ETH_TXD3 - -
M4 PG5 - - P1-USART2_CTS
L3 PG6 LCD_B3 - -
L1 PG7 SAI1_MCLK_A - -
T14 PG8 LCD_G7 - -
T13 PG9 - - P20-GPIO
T10 PG10 LED2 - -
U13 PG11 LCD_R6 - -
T9 PG12 LCD_G0 - -
U9 PG13 LCD_DE - -
P6 PG14 - - P4-USART2_RTS
R6 PG15 LCD_B0 - -
A7 PH0-OSC_IN(PH0) PH0 - -
B7 PH1-OSC_OUT(PH1) PH1 - -
E7 PH2 -
A5D
(1)
-
B1 PH3 LCD_B4 - -
F4 PH4 LCD_R4 - -
