MENU: The MENU key is used to enter the Operator Menu system (See page 21) allowing the Ï and Ð
keys to select options from the menu system. Exit the menu system by pressing any zone key
(OPP or SAME).
VOLUME/TEST
: The VOLUME/TEST key is a two (2) function key:
The VOLUME key is used with the Ï and Ð keys to adjust the Doppler volume (Aud), the Beep
volume, and the Voice volume. The first press of the VOLUME key will display Aud (0, 1, 2, 3,
or 4), the second press will display bEE P (0, 1, 2, or 3), and the third press will display UOI CE
(0, 1, 2, or 3). The Ï and Ð keys are used to increase or decrease the volume of each sound. For
each attribute, 0 is off and 3 or 4 is maximum volume. Two different Aud levels can be set – one
associated with the moving mode and the other associated with the stationary mode. The levels are
set when the radar is in the appropriate mode. When VSS is enabled, the radar will automatically
switch between moving Aud level and stationary Aud level when it switches between modes. The
bEE P and UOI CE volume levels remain the same in both stationary and moving modes.
Press and hold
the TEST key to perform a diagnostic check on the display/counting unit and
antenna. The display/counting unit will complete a processor check, memory check, and crystal
check, followed by counting unit temperature display and input voltage display, followed by the
display of speeds of 10, 35, and 65. A comprehensive test is also performed on each antenna by
the counting unit to ensure the integrity of the antenna cable and antenna electronics. PAS S or
FAI L (with tone) is indicated on the display unit after the completion of each antenna test. After
PAS S is displayed for each antenna, the radar goes into a 5-minute “fork mode” time interval
that is used for the tuning fork tests. This “fork mode” state is indicated by decimal points being
displayed in both the Front and Rear Strong Target windows simultaneously.
PS BLANK: The PS BLANK key is a dual function key:
While
a target speed is locked (moving mode) the PS BLANK key can be used to toggle between
showing the locked patrol speed or a blank patrol speed window. In addition, with no locked
speeds, if the patrol window indicates an incorrect patrol speed, the PS BLANK key can be used
to blank the patrol speed window and acquire a new patrol speed. When a VSS cable is installed,
this function is not needed and just beeps.
LIGHT: This is a dual-function key. With a single depression, the LIGHT key activates the remote control
back light for six (6) seconds. Additional depressions of the LIGHT key toggle the display
intensity through six levels of brightness, ranging from bri 1 (low) to bri 6 (high) and the
bri A (automatic) position. The auto brightness function is selected with the bri A position and
uses the front panel light sensor to select either full brightness for day operation or reduced
brightness for night operation.
14
