STALKER DSR 2X MOUNTING OPTIONS
The S DSR 2X radar system can be mounted many ways. As shown in the following drawings, Applied
Concepts has designed unique mounting options for the S DSR 2X. You can count on S to give
you the most flexible mounting options for your radar system!
200-0243-00 - Counting-Unit/Display Unit Dash Mount
Mounts Counting/ Display Unit with Velcro (or screws) on top
of the dash, radio rack, or other surface. Also, it can be used to
suspend with screws from under the dash.
200-0242-00 - Combination Dash Mount
Mounts Counting Unit, Display Unit, or both along with an
antenna on top of dash using Velcro (or screws).
POSITION ANTENNA JUST
ABOVE DASHBOARD
APPLY GLASS ADHESIVE
CLOSE TO LEFT POST
200-0502-00 - Antenna Adhesive Glass Mount
Attach to windshield or rear window with glass adhesive. A
favorite for windshield mounting.
Screws
200-0246-00 - Antenna Headliner Mount
Attaches front or rear antenna to headliner or window
trim/deck with screws. Suspends the antenna from above. Also
can be screwed into rear deck and placed upright.
Attach
Velcro
200-0244-00 - Antenna Dash Mount
Used to attach an antenna to vehicle dash, rear deck, or lightbar
with Velcro or screws.
Attach
Velcro
200-0583-00 - Antenna Swivel Dash Mount
Same as the Antenna Dash Mount (left) except this mount has
a swiveling base to allow the operator to easily change the
angle of the antenna. Attaches to the vehicle with Velcro.
44
