Stalker DSR 2X - Page 49

STALKER DSR 2X MOUNTING OPTIONS
Attach
Velcro
200-0262-00 - Antenna Mount, Dash w/suction cups
Attaches antenna to dash with suction cups and Velcro. Allows
360-degree rotation.
Attach
Display
Hood With
2 Screws
200-0252-00 - Display Hood Kit
Attaches to display to shield the LEDs from direct sunlight
during daylight operations. Also prevents LED reflections
from appearing on the windshield during night operation. Only
for non-switch display.
Clamp
Onto
Existing
Mirror
Bracket
200-0259-00 - Antenna Mirror Clamp Mount
Clamps on the existing rear view mirror bracket.
RUBBER MOLDING
SIDE WINDOW
SLIP OVER TOP
OF SIDE WINDOW
200-0504-00 - Antenna Side Window Mount
Slips over top of side window glass and can mount either one
or two antennas.
45
