START/STOP: When in Stopwatch Mode, the START/STOP key is used to start and stop the electronic timing
of the target vehicle as it enters and exits the speed measurement zone.
The operator enters the stopwatch mode by turning Stopwatch Mode ON in the Operator Menu
(See Page 28). Press the MENU key and change the StO P setting from OFF to On followed by
pressing any of the four zone keys (OPP or SAME). The operator leaves Stopwatch Mode and
returns to radar mode by again pressing any of the four zone keys.
OPP │LK/REL: FOR STATIONARY MODE
- The OPP │LK/REL key is a two (2) function key:
1. Press the OPP key to turn-on the corresponding transmitter (if it is in hold) and directly
select the Opposite lane speed zone for the associated antenna.
2. Once the Opposite lane speed zone is selected, the OPP │LK/REL key now becomes a
Lock/Release key. While a strong target is displayed in the corresponding Target Window,
press the LK/REL key to lock the strong speed in the Fast Window. Press again to release.
In stationary mode, both speed zones (OPP/SAME stationary mode) are selected for an antenna
when both the OPP mode key and the SAME mode key are pressed within 1 second of each
other for either (or both) antenna. To exit the OPP/SAME stationary mode, press the Hold key,
and then press a zone key.
FOR MOVING MODE
- The OPP │LK/REL key is a two (2) function key:
1. Press the OPP key to turn-on the corresponding transmitter (if it is in hold) and directly
select the opposite lane speed zone for the associated antenna.
2. Once the Opposite lane speed zone is selected, the OPP │LK/REL key now becomes a
Lock/Release key. While a strong target is displayed in the corresponding Target Window,
press the LK/REL key to lock the strong speed in the Fast Window. Press again to release.
Patrol speed will also be locked and stored internally until the patrol vehicle is stopped. Then
the locked patrol speed will be displayed in the Patrol window.
XMIT │HOLD: The XMIT │HOLD key is used to place the associated antenna in transmit mode or hold (standby)
mode. The XMIT icon will toggle (On/OFF) to indicate either transmit mode or hold mode.
During hold mode, HLd will be displayed in the lock window (for that antenna) and along with all
currently selected mode icons and arrows associated with that antenna (unless that lock window
contains a locked target).
Ï and Ð: The Ï key and the Ð key (located on theXMIT/HOLD keys) are used with the MENU key to
select options from the Operator Menu and the Option Menu.
SAME │LK/REL: FOR STATIONARY MODE
- The SAME │LK/REL key is a two (2) function key:
1. Press the SAME key to turn-on the corresponding transmitter (if it is in hold) and directly
select the Same lane speed zone for the associated antenna.
2. Once the Same lane speed zone is selected, the SAME │LK/REL key now becomes a
Lock/Release key. While a strong target is displayed in the corresponding Target Window,
press the LK/REL key to lock the strong speed in the Fast Window. Press again to release.
In stationary mode, both speed zones (OPP/SAME stationary mode) are selected for an antenna
when both the OPP mode key and the SAME mode key are pressed within 1 second of each
other for either (or both) antenna.
FOR MOVING MODE
- The SAME │LK/REL key is a two (2) function key:
1. Press the SAME key to turn-on the corresponding transmitter (if it is in hold) and directly
select the Same lane speed zone for the associated antenna.
2. Once the Same lane speed zone is selected, the SAME │LK/REL key now becomes a
Lock/Release key. While a strong target is displayed in the corresponding Target Window,
press the LK/REL key to lock the strong speed in the Fast Window. Press again to release.
Patrol speed will also be locked and stored internally until the patrol vehicle is stopped. Then
the locked patrol speed will be displayed in the Patrol window.
MENU: The MENU key is used to enter the Operator Menu system (See page 21) allowing the Ï and Ð
keys to select options from the menu system. Exit the menu system by pressing any zone key
(OPP or SAME).
16
