associated with the moving mode and the other associated with the stationary mode. The levels are
set when the radar is in appropriate mode. When VSS is enabled, the radar will automatically
switch between moving Aud level and stationary Aud level when it switches between modes. The
bEE P and VOI CE volume levels remain the same in both stationary and moving modes.
Press and hold
the TEST key to perform a diagnostic check on the display/counting unit and
antenna. The display/counting unit will complete a processor check, memory check, and crystal
check, followed by counting unit temperature display and input voltage display, followed by the
display of speeds of 10, 35, and 65. A comprehensive test is also performed on each antenna by
the counting unit to ensure the integrity of the antenna cable and antenna electronics. PAS S or
FAI L (with tone) is indicated on the display unit after the completion of each antenna test. After
PAS S is displayed for each antenna, the radar goes into a 5-minute “fork mode” time interval
that is used for the tuning fork tests. This “fork mode” state is indicated by decimal points being
displayed in both the Front and Rear Strong Target windows simultaneously.
PS BLANK: │ MENU
: The PS BLANK/MENU key is a dual function key:
While
a target speed is locked (moving mode) the PS BLANK key can be used to toggle between
showing the locked patrol speed or a blank patrol speed window.
In addition, with no locked speeds, if the patrol window indicates an incorrect patrol speed, the PS
BLANK key can be used to blank the patrol speed window and acquire a new patrol speed. When
a VSS cable is installed, this function is not needed and just beeps.
Press and hold the MENU
key to enter the Operator Menu system (See page 21) allowing the Ï
and Ð keys to select options from the menu system. Exit the menu system by pressing any zone
key (OPP or SAME).
LIGHT:
This is a dual-function key. With a single depression, the LIGHT key activates the remote control
back light for six (6) seconds. Additional depressions of the LIGHT key toggle the display
intensity through six levels of brightness, ranging from bri 1 (low) to bri 6 (high).
ON / OFF: This key turns the radar on and off.
20
