Self Testing Modes 2X Display Unit
comprehensive test is also performed on both antennas by the
isplay/counting unit to ensure the integrity of the antenna cables
and electronics. After all the tests are completed, PASS (Fig. 46)
along with a 4-beep “happy” tone indicate successful test
completion. FAIL along with a 20-beep tone indicates a failed self-
test.
A
d
Fig. 46
After PASS is displayed for both antennas (Figures 47-50), the rad
goes into a 5-minute “fork mode” time interval (Fig 51) th
for the tuning fork tests (see Tuning Fork Test Section on Page 35).
ar
at is used
Fig. 47
Fig. 48
Fig. 49
Fig. 50
Automatic Self-Test
Fig. 51
n automatic self-test (indicated by a 4-beep “happy” tone) is
performed every 10 minutes while S
DSR 2X is transmitting.
Switching antennas from XMIT to HLd to XMIT will reset the 10-
minute timer.
A
34
