T15h Tag Deployment & User Guide
53
Note: The images used in this section are of the T15e Tag. The procedures are
the same for the T15h Tag.
Connecting the Power Adapter
IMPORTANT!
Batteries are recommended as a backup if external power is used.
It is highly recommended to use an approved STANLEY power supply with
the TAG (SKU: ADP-1500-U, ADP-1500-E). If a different power supply is
used, ensure to connect the power cable to the power outlet first and then
to the T15h Tag -C port.
NOTE: The AC/DC adaptor must be safety-approved according to
IEC/EN/UL 60950-1 with a rated voltage of 5Vdc and rated current up to 3A
maximum.
The T15h Tag is not designed to be powered
T15h Tags are compatible with USB 2.0 cables. Using USB 3.0 cables may
result in inconsistent behavior of the tag.
Make sure the plug is tightened to the tag.
The T15h Tag has 1 USB-C port for power only. The power USB-C connector
has a tightening screw:
Plug a connector into the power port and tighten the tightening screw. Note:
The T15h Tag has only one connector port in the middle.
