Channel Level Meter
14
3.2.9 Channel Level Meter
Figure 3.17
The Channel Level Meter indicates the volume of each channel like
a tradional DJ mixer. (Figure 3.17)
3.2.10 Channel Strip
Figure 3.18
The Slider, Buon, Mode Switchers, Channel Fader, Level Meter, and
Monitor Buon all constute a tradional channel strip. The Channel
Strip can be switched between decks A/C on the le side and B/D
on the right side of the SCS.3m to control up to 4 soware channels.
(Figure 3.18)
