Alarm function RF
program table
Variant 1 Variant 2 Variant 3 Variant 4
№14 - CH # 2 output
pulse time
(yellow-red wire)
2-step unlock
0.8 sec
Flexy CH HoodLock
Engine run
under arm &
Turbo(Follow
SF#1)
№15 - CH # 3 output
pulse time (yellow-
white wire)
Engine stop
delay 1 sec
then output 1 sec
(bypass door)
Flexy CH
Disable light
relay
Parking light
ash
Disable light
relay
Impulse control
light signals
№16 - Range check
timer
O 3 min 5 min 7 min
№17 - Door input
selection
Door (-) Door ( + ) Door ( + ) Door ( + )
№18 - GSM protocol
selection
V1.0 V2.0 V2.0 V2.0
№19 - CH # 5 output
pulse time (black-
white wire)
Start killer Flexy CH Unlock(MCU) On/O
№20 - CH # 6 output
pulse time (yellow-
orange wire)
Eberspacher
(Digital)
Flexy CH HoodLock Webasto(Digital)
№21 -GSM OUT
command selection
CH1 CH2 CH6 CH5
№22 - Car Alarm
Mode function
Normal Slave (15 sec) Slave (20 sec) Slave (30 sec)
№23 - Event for
search Tag or CAN
PINCODE
function for Slave
mode
Lockout pin Door trigger
IGN trigger
OR transfer
to KEY
IGN trigger
OR transfer
to KEY
