StarLine A93, StarLine A63
70
Additional CH 7 control
(locking relay, connector 1)
Versions of CH 7 activation are dened by function 24 table
№1 (see page 113)
Channel activates automatically
Version 1:
Central lock control «LOCK»
This version is intended for power central lock control. Schematic see
installation manual.
Version 2:
FLEX programming
For this version, an activation method (by remote control or
automatically upon event happens) duration and the delay
of the output signal can be programmed. For more
information about exible programming see installation
manual.
Version 3:
imitation of pressing the brake pedal
or the clutch.
Version 4:
Duplication of the signal on the
black-yellow wire of the power module
Variants 3 and 4 are necessary for the implementation of the
engine start-up functions, for details, see the installation
instructions at www.starline.ru
Type of additional equipment connected to the channels
№7, is specied during the installation of car alarm.
