User’s manual
71
Additional CH 8 control
(unlocking relay, connector 1)
Versions of CH8 activation are dened by function 25 table
№1 (see page 113)
Channel activates automatically
Version 1:
Central lock control «UNLOCK»
This version is intended for power central lock control. Schematic see
installation manual.
Version 2:
FLEX programming
For this version, an activation method (by remote control or
automatically upon event happens) duration and the delay
of the output signal can be programmed. For more
information about exible programming see installation
manual.
Version 3:
imitation of pressing the brake pedal
or the clutch.
Version 4:
Duplication of the signal on the pink
wire of the Х3 connector
Variants 3 and 4 are necessary for the implementation of the
engine start-up functions, for details, see the installation
instructions at www.starline.ru
Type of additional equipment connected to the сhannels
№8, is specied during the installation of car alarm.
