Trailer Manufacturer
This manual contains instructions to correctly install the Omaha Standard DTH series dump
trailer hoist and components. If components are used that are not provided by Omaha Standard,
then it is the responsibility of the trailer manufacture to ensure proper installation and
operation of the system.
The manual provides operation instructions that are specific to Omaha Standard supplied com-
ponents. If Omaha Standard does not supply the hydraulic system, then it is the responsibility
of the trailer manufacturer to provide or create the proper manual for the hydraulic system to
ensure the safe operation of the hoist and hydraulic system. It is important that this manual and
the proper hydraulic operator’s manual are given to the end user of the trailer.
Omaha Standard provides decals that are to be affixed to the trailer. These decals are specific
toe Omaha Standard supplied components. Since we do not know the requirements of your
trailer, Omaha Standard is not implying that these are the only decals needed for your trailer. If
these decals do not apply or more decals required, then it is the responsibility of the trailer
manufacturer to provide those decals as needed.
Hydraulic System
Omaha Standard hoists can be supplied with an Omaha Standard hydraulic System. These
hydraulic systems and their hydraulic components have been tested and are compatible with
the DTH series dump trailer hoists.
IF YOU SUBSTITUTE HYDRAULIC COMPONENTS, IT IS THE TRAILER
MANUFACUTER’ S RESPONSIBILITY TO ENSURE THAT THE SUBSITITUED
COMPONENTS ARE COMPATIBLE WITH THE COMPONENTS SUPPLIED BY
OMAHA STANDARD. INCOMPATIBLE COMPONENTS COULD RESULT IN FAILURE
OF THE HOIST OR OTHER COMPONENTS, WHICH COULD CAUSE
PROPERTY DAMAGE, SEVERRE INJURY OR EVEN DEATH
All Omaha Standard warranty will be voided if Omaha Standard determines that the
substituted parts were incompatible with those components supplied by Omaha Standard.
Omaha Standard has provided several hoist hydraulic parameters in the table below to be used
as a general guide. To ensure component compatibility, consult Omaha Standard.
Hoist Manual 415/515/519 520/625/630
Maximum Hydraulic Flow Rate 4 GPM 6 GPM
Maximum Hydraulic Pressure for raising body 3250 PSI 3250 PSI
Maximum Hydraulic Pressure for lowering body 1500 PSI 1500 PSI
