Stepp SPHD series - Operating Instructions; To Raise Body; To Lower Body

164
OMAHA STANDARD
Operating Instructions
A. To Raise Body:
WARNING! FOR SAFERTY REASONS, OPERATE HOIST ONLY WITH
TRAILER PARKED ON LEVEL AND FIRM GROUND.
1. Depress “up” button on control station
2. When hoist reaches desired height, release “up” button. Hoist will hold body in position.
B. To Lower Body:
CAUTION!: DO NOT POWER DOWN HOIST WITH PROP SUPPORTING BODY
ON A DOUBLE ACTING SYSTEM.
NOTE: To avoid getting air into system or overflowing pump reservoir, always power down a
double acting hoist.
1. If body is EMPTY, push the “down” button
C. To operate the safety Body Prop (see figure 1, page 3):
WARNING! ALWAYS USE BODY PROP WHEN PERFORMING AND ACTIVITY
UNDER A RAISED BODY. USE SAFETY BODY PROP TO SUPORT ONLY AN
EMPTY BODY!!
1. To prop a raised body
A. Raised body to a height slightly beyond reach of prop
B. Shut off all power
CAUTION! MAKE SURE NO ANAUTHORIZED PERSONNEL HAVE ACCESS
TO CONTROLS
CAUTION! DO NOT USE SAFETY PROP TO SUPPORT A LOADED BODY
C. Swing prop upwards until pin locks into collar
D. Using controls, lower body slowly until hoist upper cross tube come to rest on prop.
2. To place body safety prop in storage position
A. Raise body beyond reach of prop
B. Shut off power
CAUTION! MAKE SURE NO UNAUTHORIZED PERSONNEL HAVE ACCESS
TO CONTROLS
C. Pull out on pin to release prop from collar
B. Lower prop to horizontal, stored position and snap into hanger bracket.
