181
OMAHA STANDARD
SA ELECTRIC PUMP INSTALLATION
ITEM PART NO DESCRIPTION QTY
1 1300040 Pump complete, M319-0175 SA Electric w/ Push Button 1
3 1030125 Bolt, 3/8-16 X 1 HHCS GR8 Zinc Plated 4
4 1070120 Washer, 3/8” Zinc Plated Flat 4
5 1061155 Nut, 3/8-16 NYlock GR8 Zinc Plated 4
6 1030520 Bolt, 5/8-11 X 1 3/4 HHCS GR8 Zinc Plated 4
7 1061200 Nut, 5/8-11 NYlock GR2 Zinc Plated 4
8 3125561 Hose, 3/8” X 54”, 3/8 Female JIC Swivel X 3/8 Male O-Ring 1
9 3125500 Cylinder port breather plug, 3/8 male O-ring 1
10 3125502 Adapter elbow, 3/8” male NPTF X 3/8 Male JIC 1
11 3122157 Pump mount bracket channel 2
