183
OMAHA STANDARD
DA ELECTRIC PUMP INSTALLATION
ITEM PART NO. DESCRIPTION QTY.
1 1300094 Pump complete, M3551-0105 DA electric w/ push button 1
3 1030125 Bolt, 3/8-16 X 1 HHCS GR8 Zinc Plated 4
4 1070120 Washer, 3/8” Zinc Plated Flat 4
5 1061155 Nut, 3/8-16 NYlock GR8 Zinc Plated 4
6 3122157 Pump Mount Bracket Channel 2
7 1030520 Bolt, 5/8-11 X 1 3/4 HHCS GR8 Zinc Plated 4
8 1061200 Nut, 5/8-11 NYlock GR2 Zinc Plated 4
9 3125560 Hose, 3/8” X 72”, 3/8” Female JIC Swivel X 3/8 Male O-Ring 1
10 3125561 Hose, 3/8” X 54”, 3/8” Female JIC Swivel X 3/8 Male O-Ring 1
11 3125524 Adapter elbow, 3/8” male NPTF X 3/8 Male JIC O-Ring 2
To Next Page
