13.6 Tank Dimensions and Capacity
Tank length (internal) 745.0 mm (29.3 in.)
Tank width (internal) 375.0 mm (14.8 in.)
Tank depth (internal)
Unity: 215.0 mm (8.5 in.)
Unity 20: 253.4 mm (10.0 in.)
Tank liquid volume (maximum) 35.0 liters (9.2 US gal)
Tank total volume
Unity: 59.4 liters (15.7 US gal)
Unity 20: 69.9 liters (18.5 US gal)
13.7 Unity Basket Dimensions and Capacity
Internal length 598 mm (23.5 in.)
Internal width 341 mm (13.4 in.)
Internal depth 104 mm (4.1 in.)
Maximum load weight 12.0 kg (26.4 lb)
Flush port connections 8
13.8 Unity 20 Basket Dimensions and Capacity
Internal length 610 mm (24.0 in.)
Internal width 324 mm (12.8 in.)
Internal depth 139 mm (5.5 in.)
Maximum load weight 16.0 kg (35.2 lb)
Flush port connections 8
SPECIFICATION 111
InnoWave Unity & Unity 20 Operator Manual
