PART
48
764333-676
UNITS PER
ASSEMBLY
S
V
C
FIG. &
ITEM
NO.
PART
NUMBER
18- HARNESS/CABLE ASSEMBLIES.................................................... X
1 10004501 CABLE, Internal Monitor Cable .......................................................... 1
2 P 136817 135 HARNESS, Transducer Wire (P6 to PT1).......................................... 1
3 10004506 CABLE, Analog (P5A to P5B) ............................................................ 1
4 P 146665 363 CABLE, DC Input (P4 to P12) ............................................................ 1
5 P 146665 365 HARNESS, DC Power (P2 to P10 and P11)...................................... 1
6 P 146665 364 HARNESS, AC Output (P8 to P3)...................................................... 1
7 P 093922 498 HARNESS, Display (P1 to Display).................................................... 1
8 P 093922 499 ASSEMBLY, Printer Harness (P2 to Printer)...................................... 1
9 P 136817 129 HARNESS, Serial Port (P3 to Panel) ................................................. 1
10 300064 HARNESS, High Voltage Wire (LS1; Power Supply Line Filter; Fan;
SSR1/2/3 and 4 P1; HTR1; P2; CB1; CB2; COMP)....................... 1
11 10004499 HARNESS, DC Power Supply (Not Shown) (Power Supply to J1) .... 1
12 300068 ASSEMBLY, Cable (Not Shown) (Pump to Ground).......................... 1
13 300069 ASSEMBLY, Cable (Not Shown) (Compressor to Ground)................ 1
14 300065 ASSEMBLY, Cable (Not Shown) (Heater to Filter) ............................ 1
15 500025 ASSEMBLY, Cable (Not Shown)........................................................ A/R
16 400022 FITTING, Electric Cord, Seal (Not Shown)......................................... 1
17 300071 ASSEMBLY, Power Cord (Not Shown) (AC Power) .......................... 1
To Next Page
