Steris SYSTEM 1E Service Manual

2-10
764333-675
Use right or left arrows (< or >) to select pressure units.
Press SAVE VALUES touch pad to continue. Display
shows:
ENABLE PC?
YES NO
(PC) selection is used for PC option. This requires a
separate kit. If PC is to be enabled, select YES. If not
enabled, select NO. If NO is selected, display advances
to LANGUAGES. Select YES if connected to PC. Press
SAVE VALUES touch pad to continue. Display shows:
PC NODE ADDRESS=
XX
This is used for PC applications. Follow PC kit
instructions to identify node address. Enter correct
address by using number keypad. Press SAVE
VALUES touch pad to continue.
Display shows:
LANGUAGE
ENGLISH
Use left or right arrows (< or >) to select desired
language. Press SAVE VALUES touch pad. Display
shows:
* UPDATING *
* MEMORY *
The printer prints: * Change Value X:XX:XXA or P. See
Figure 2-5. The printer prints values selected in normal
Operating Mode.
2.1.6 Calibration
The Calibration section of the Service Mode has four
sub-sections:
• CALIBRATION routine – for adjusting pressure,
temperature, concentration and UV system.
• RESTORE routine – to review or enter calibration
data.
• VIEW routines – to review real time in each of the
analog channels.
• PRINT routine – for printouts of current calibration
data.
• Calibration
NOTE: During the Calibration routine, when the control
displays: STABILIZING, the control is waiting for the
temperature or pressure to be at a stable point to allow
for setting the correct value. If the control remains in
STABILIZING and does not proceed, it would indicate
that there is a fault that must be repaired before
calibration can be accomplished successfully.
When the display shows:
MFG TESTS
VALUES CALIB
Select CALIB, then press SAVE VALUES touch pad.
Display shows:
CALIB RESTORE
VIEW PRINT
Select CALIB, then press SAVE VALUES touch pad.
Display shows:
PRESS TEMP
CONC MORE
S E T U P
D-MM-YY H:MM:SSP
ACCESS CODE: NO
OPERATOR ID: NO
PATIENT ID: NO
DEVICE ID: NO
PROCEDURE ID: NO
PHYSICIAN ID: NO
INFORMATIVE OPTION: NO
DUPLICATE PRINT: NO
COMPLETE TONE: YES
MAXPURE FILTER
FILTER START DATE: D-MM-YY
CYCLE COUNT XXXX
-------------------------
Figure 2-5. Setup
