2-7
764333-675
VALVES INPUT
CONSOLE MORE
Select CONSOLE, then press SAVE VALUES touch
pad.
Display shows:
KEYPAD DIPSW
DISPLAY
DIP SW (Dip Switch)
NOTE: Only NOSHOK used. Ametek - IPTG and
Ametek - MPTG information shown for reference only.
Select DIP SW, then press SAVE VALUES touch pad.
Display shows:
1234
1111
The 1234 indicates the control board dip switch
position and number directly below indicates status of
the switch. 1 indicates OFF, and 0 indicates ON.
The dip switch definitions are as follows:
Position 1 and 2 select model of pressure
transducer. Check Transducer Model No.:
Position 3 direction of the printer (0= print from
bottom up; 1= print from top down; 1 is default
setting.)
Position 4 printer self test mode (0= test mode; 1=
normal operation). Printer prints: **THIS IS A
SELF TEST**. Access dip switch through cover
panel on backside of control panel. Locate plug
button and remove. Use a small plastic screwdriver
or pen to activate switch.
Select CANCEL. Display shows:
MFG TESTS
VALUES CALIB
Select TESTS, then press SAVE VALUES touch pad.
Display shows:
VALVES INPUT
CONSOLE MORE
Select CONSOLE, then press SAVE VALUES touch
pad. Display shows:
KEYPAD DIPSW
DISPLAY
•Display
Select DISPLAY, then press SAVE VALUES touch
pad. Display shows:
■■■■■■■■■■■■■■■■
■■■■■■■■■■■■■■■■
The display responds by lighting up all pixels in
display. Inspect display for burned out pixels. Select
CANCEL. Display shows:
MFG TESTS
VALUES CALIB
Select TESTS, then press SAVE VALUES touch pad.
Display shows:
VALVES INPUT
CONSOLE MORE
•More
Select MORE, then press SAVE VALUES touch pad.
Display shows:
Position 1: Position 2: Trans. M/N:
1(off) 1(off) NOSHOK
0(on) 1(off) Ametek - IPTG
1(off) 0(on) Ametek - MPTG
