•Service
SERVICE SELECT, then press SAVE VALUES touch
pad. Display shows:
MFG TESTS
VALUES CALIB
Printer also prints SERVICE MODE information. See
Figure 2-2.
2.1.3 MFG (Manufacturing)
The manufacturing section is used by the factory prior
to new unit shipment; however, several routines are
useful in the field. Select MFG, then press SAVE
VALUES touch pad. Display shows:
CHECK SF HOLD
AIRTEST BATTERY
•Check
CHECK is a routine used by the factory that checks the
components listed in this procedure. Select CHECK,
then press SAVE VALUES touch pad. Display shows:
AIR TEST TIME
XX MINUTE
Figure 2-3. Service Mode Program Tree
MFG TESTS
VALUES CALIB
CALIB
MFG
TESTS
VALUES
CALIB
RESTORE
VIEW
PRINT
- VALVES
- INPUT
- CONSOLE
- MORE
- CYCLE COUNT
- RUN TIME
- SERIAL NO.
- PRESSURE UNITS
- ENABLE PC (option)
- PC NODE ADDRESS
- LANGUAGE
- PRESS
-TEMP
- CONC
- PRESS
-TEMP
- CONC
- CHECK
- SF HOLD
- AIRTEST
- BATTERY
- KEYPAD
- DIPSW
- DISPLAY
- HPP TEST
- DIAGVAL
- LISTS
- HISTORY
- PRESS
-TEMP
- CONC
- Print
Errors
- Print
Cycle
Data
- UV
- UV
- MORE
- UV
- DEFAULT
