Steris SYSTEM 1E Service Manual

2-17
764333-675
2.2 ENHANCED OPERATOR MODE
When this mode is selected, display reverts to a
standard operator mode screen; however, while cycle
is progressing, pressing STATUS button allows
display to show various parameters that are not seen
in normal operation. These additional displays are as
follows:
• Thermocouple temperatures TC1, TC2 and TC3
(read in degrees C)
• Concentration monitor
• Pressure (read by transducer, read in PSI)
• UV Intensity (read by UV monitor)
•Cycle phase
* Time = length of time in phase
** Conc = Concentration count at end of phase
Under normal conditions, display shows
OPERATING, with a projected time to completion.
Pressing the STATUS button shows the first alternate
display. Pressing again shows second alternate
display, and so on. Pressing PAPER FEED touch pad
forces unit to print current status of LS6 and float
switch.
NOTE: The display reverts back to the OPERATING
display after a few seconds, so it is necessary to
continue pressing the STATUS button to continue
showing the alternate displays.
INLET TEMPERATURE
LOW PT =XXXX
LOW RAW =XXXX
HIGH PT =XXXX
HIGH RAW =XXXXX
OUTLET TEMPERATURE
LOW PT =XXXX
LOW RAW =XXXX
HIGH PT =XXXX
HIGH RAW =XXXXX
DRAIN TEMPERATURE
LOW PT =XXXX LOW RAW =XXXX
HIGH PT =XXXX
HIGH RAW =XXXXX
CONCENTRATION MONITOR
LOW RAW = XXXX
HIGH RAW = XXXX
PRESSURE TRANSDUCER
LOW RAW = XXXX
UV LAMP SENSOR
LOW PT = X.X mA
LOW RAW = XXXXX
HIGH PT = XX.X mA
HIGH RAW = XXXXX
Figure 2-9. Calibration Data Printout
SYSTEM 1E
DATE: mm-dd-yy
CYCLE START: hh:mm:ssp
OPERATOR:_______________
LOAD ID:________________
REMARKS:________________
________________
________________
________________
==========================
TIME* CONC**
WARM/MIX XX.X MIN XXX
EXPOSURE XX.X MIN XXX
RINSE: 1 XX.X SEC XXX
RINSE: 2 XX.X SEC XXX
DRAIN: XX.X SEC XXX
TOTAL: XX.X MIN XXX
==========================
TEMP: XX.X - XX.X DEG. C
CONCENTRATION: XXX
EXPOSURE TIME: X.X
FILL TIME: X.X
INLET TEMP: XX DEG. C
OPERATOR: ______________
SERIAL # XXXXXXXXXX
CYCLE COUNT: XXX
CYCLE COMPLETE:hh:mm:ssp
CHAMBER OPENED:hh:mm:ssp
Figure 2-10. Cycle Data
Printout
