SPECTRE NANO OSDP
TM
© STid – MU_ULTRYS_V3.0.1_EN
Possibility to define the reporting format according to the size of the identifier, the offset and
the reading direction.
WARNING
UHF ID Size + Offset should not be larger than the EPC size of the tag used. Otherwise the ID
will not be returned to the system.
Example 1:
ID encoded in the Tag:
AABBCCDDEEFF001122334455
Formatting:
ID Formated:
22334455
Size of the credential sent to the system:
Data sent to the system:
22334455
Example 2:
ID encoded in the Tag:
AABBCCDDEEFF001122334455
Formatting:
ID Formated:
55443322
Size of the credential sent to the system:
Data sent to the system:
55443322
Example 3 :
ID encoded in the Tag:
AABBCCDDEEFF001122334455
Formatting:
ID Formated:
AABBCCDD
Size of the credential sent to the system:
Data sent to the system:
AABBCCDD
Example 4 :
ID encoded in the Tag:
AABBCCDDEEFF001122334455
Formatting:
ID Formated:
DDCCBBAA
Size of the credential sent to the system:
Data sent to the system:
DDCCBBAA
