OPERATION

Operation

12 | WPF basic www.stiebel-eltron.com

INFO WPM Meaning

external Outside temperature

ACT ROOM T FE7 Actual room temperature for heating circuit 1 (HC1) or heating circuit 2 (HC2) (will only be displayed if the FE7 remote control is connected)

SET ROOM T FE7 Set room temperature for heating circuit 1 or heating circuit 2 (will only be displayed if the FE7 remote control is connected)

REL HUMIDITY Relative humidity

DEW POINT TEMP Dew point temperature

SET DHW TEMP Set DHW temperature

ACTUAL RTRN T Actual heat pump return temperature - heating circuit 1

SET RTRN TEMP Set heat pump return temperature for heating circuit 1 (HC1). Fixed temperature is displayed for fixed temperature control

ACTUAL MIXER T Actual mixer flow temperature - heating circuit 2

SET MIXER TEMP Set mixer flow temperature - heating circuit 2

FIXED VALUE Set fixed temperature for heating circuit 1

SET BUFFER T Set buffer temperature (highest set value of heating circuits H1 and H2 (H3 if MSM is installed). Fixed temperature will be displayed for

set-value control)

ACTUAL FLOW T Actual heat pump flow temperature

SET FLOW HTG Set central heating flow temperature

ACTUAL SRCE T Actual heat source temperature

SET SRCE TEMP Minimum source temperature

DUAL-MODE HTG Dual-mode point - central heating

DUAL-MODE DHW Dual-mode point - DHW

HEAT LIMIT Limit temperature - central heating

DHW LIMIT Limit temperature - DHW

SYST FROST PRO System frost protection temperature

HOT GAS TEMP Compressor outlet temperature

HIGH PRESSURE HIGH PRESSURE
