DocID027351 Rev 3 37/100
UM1855 Hardware layout and configuration
99
2.15.1 Limitations
LCD glass module operation is exclusive with all other features of the board.
Table 18. LCD glass element mapping - segments 30 to 39
SEG30 SEG31 SEG32 SEG33 SEG34 SEG35 SEG36 SEG37 SEG38 SEG39
COM0 10e 11e 12e 13e 14e 15e 16e 17e 18e 19e
COM1 10f 11f 12f 13f 14f 15f 16f 17f 18f 19f
COM2 10c 11c 12c 13c 14c 15c 16c 17c 18c 19c
COM3 10d 11d 12d 13d 14d 15d 16d 17d 18d 19d
COM4 10j 11j 12j 13j 14j 15j 16j 17j 18j 19j
COM5 10i 11i 12i 13i 14i 15i 16i 17i 18i 19i
COM6 10h 11h 12h 13h 14h 15h 16h 17h 18h 19h
COM7 10g 11g 12g 13g 14g 15g 16g 17g 18g 19g
