STMicroelectronics STM32L476G-EVAL User Manual

DocID027351 Rev 3 63/100
UM1855 Connectors
99
39 GND - -
2+3V3 - -
4 PG7 LPUART_TX Remove R119, R189
6 PA11 USBOTG_DM Remove R3
8PA14 TCK/SWCLK
Don’t use Trace connector CN12 and JTAG
connector CN15
10 PG5 A15
Remove R18 to deselect SRAM U2
Remove R43 to deselect Flash memory U5
12 PG3 A13
Remove R18 to deselect SRAM U2
Remove R43 to deselect Flash memory U5
14 PG4 A14
Remove R18 to deselect SRAM U2
Remove R43 to deselect Flash memory U5
16 PD1 D3
Remove R18 to deselect SRAM U2
Remove R43 to deselect Flash memory U5
18 PD4 FMC_NOE
Remove R18 to deselect SRAM U2
Remove R43 to deselect Flash memory U5
20 PG9 FMC_NE2 Remove R43
22 GND - -
24 PD6
SAI1_SDA,
FMC_NWAIT
Remove R53, open SB10
26 PF1 A1
Remove R18 to deselect SRAM U2
Remove R43 to deselect Flash memory U5
28 D5V - -
30 PC13 Wake-up Remove R244
32 PF2 A2
Remove R18 to deselect SRAM U2
Remove R43 to deselect Flash memory U5
34 PF3 A3
Remove R18 to deselect SRAM U2
Remove R43 to deselect Flash memory U5
36 GND - -
38 PF5 A5
Remove R18 to deselect SRAM U2
Remove R43 to deselect Flash memory U5
40 PB6 USART1_TX Remove R118
Table 35. Daughterboard extension connector CN7
Pin Description
Alternative
Functions
How to disconnect Alternative functions to
use on the extension connector
1GND - -
3 PE14 D11 -
Table 34. Daughterboard extension connector CN6 (continued)
Pin Description
Alternative
Functions
How to disconnect Alternative functions to
use on the extension connector
