Commissioning - SD6 and SIMATIC S7 with PROFINET
5
Operation manual PROFINET
5 Commissioning - SD6 and
SIMATIC S7 with PROFINET
You want to operate several drive controllers in conjunction with the Siemens
SIMATIC S7-1500 controller and a PROFINET network.
The following chapter describes the commissioning of the named systems with
the aid of the STOBER Software DriveControlSuite DS6 as well as the
Siemens Engineering Framework "Totally Integrated Automation Portal"
(TIA Portal).
To be able to implement the individual commissioning steps exactly, we require
the following system environment:
• Siemens SIMATIC S7-1500
• Siemens Totally Integrated Automation Portal V13
• STOBER SD6A drive controller with PN6 communication module
• STOBER DS6 DriveControlSuite from version 6.1-A
The systems must be cabled and supplied with the control voltage.
Commissioning is divided into the following steps ...
1. DriveControlSuite: Configure drive controller
The PN6 communication module in conjunction with the STOBER device
controller are activated separately for each drive controller subscribing on
the bus system in the DriveControlSuite. Associated PROFINET-specific
settings such as parameterization and assignment of the process data
channels are also configured for data transfer for each drive controller.
2. TIA Portal: map and configure PROFINET network
The TIA Portal provides a platform in which the PROFINET hardware
environment can be mapped, set up and saved as a global project
configuration.
5.1 DS6: Configure drive controller
To be able to configure all drive controllers of the bus system via the
DriveControlSuite, you must record them as part of a project. Afterwards
specify the general PROFINET settings and define the process data that will
be transferred.
Perform the steps included in the following chapters in the specified order!
5.1.1 Project drive controller and axis
We recommend recording all drive controllers in the DriveControlSuite
subscribing to the bus system in one project and under one module.
1. Start the DriveControlSuite and click on Create new standard project.
The project planning window opens, the Drive controller button is
active.
Project drive controller
2. Properties tab:
specify the necessary characteristics of the drive controller.
3. Drive Controller tab:
select the device type that corresponds to the drive controller.
The latest firmware version is activated by default.
4. Option modules tab:
select the PN6A communication module.
5. Device controller tab:
select the STOBER device controller as well as PROFINET Rx and
PROFINET Tx for the transfer of the process data.
