Operation manual PROFINET
6.6 Parameter reference
The following drive controller parameters are important for communication via
PROFINET.
• A90 – A93 PZD Setpoint Mapping Rx
Parameter values that are transferred from the drive controller to the
controller.
• A94 – A97 PZD ActValue Mapping Tx
Parameter values that are transferred from the controller to the drive
controller.
• A100 Fieldbus scaling
Definition of how the PZD elements are represented for the transfer.
• A109 PZD timeout
Monitoring cyclically transferred PZD by the definition of a timeout.
• A270[x] PN Port X20x state
State of the Ethernet port.
• A271 PN state
State of the PROFINET bus.
• A272 PN Module/submodule
how the process data communication was configured from the controller.
• A273 Device name, A274 PN IP address, A275 PN subnet mask, 
A276 PN Gateway
Device name, IP address, subnet mask and Gateway of a drive controller.
• A278[5] – A278[8] PN diagnostics
Possible cause for cabling errors or EMC problems.
• A279[x] PN MAC addresses
MAC address of the PN6 Port X200.
