ID 442710.00 16WE KEEP THINGS MOVING
Commissioning - SD6 and SIMATIC S7 with PROFINET
5
Operation manual PROFINET
5.1.5 Transfer project configuration
To be able to transfer a project configuration to one or more drive controllers as
part of an IGB network, you must connect your computer to the network.
Requirement:
the IGB interfaces of the drive controller are connected to each other and the
control board is switched on (24V
DC
supply).
5.1.6 Save project configuration
Requirement:
You have transferred the project configuration to a drive controller.
1. Mark the module in the project tree under which you have recorded the
drive controller concerned and click on Setting up a connection.
The connection window opens.
2. Direct connection > Column IGB IP address tab:
Mark the IP address you want to connect with and confirm with OK.
The assignment window opens.
3. For each drive controller, assign the Send to drive controller action in the
Method column, assign a drive controller in the In project column and
confirm the assignment with Start.
The project file is transferred to the selected drive controller.
1. Mark the drive controller concerned in the project tree and click on
Wizards > Axis > Save values.
The storage wizard opens.
2. Save the project configuration in the drive controller by setting A00[0] Start
to 1: active.
3. The configuration changes are only effective when the drive controller is
restarted. Click on Restart.
The restart wizard opens.
4. Restart the drive controller by setting A09[0] Start to 1: Active.
5. Reestablish a connection to the drive controller.
6. Transfer and save the project configuration to all drive controllers of your
bus system.
