Commissioning - SD6 and SIMATIC S7 with PROFINET
5
Operation manual PROFINET
5.2.4 Configure IO controller
If necessary, you can change the preconfigured IP address and subnet
address of the IO controller.
Requirement:
You are in the TIA network view.
5.2.5 Configure IO devices
In this step, specify the data volumes of each IO device of your PROFINET IO
system to be transferred and name the IO devices according to the PROFINET
name conventions. If the respective IP addresses of the IO devices are not
automatically assigned by the IO controller, change the default addresses. In
addition you also have the option to configure the monitoring of the IO-data
exchange via the so-called IO cycle.
Requirement:
You are in the TIA network view. The hardware catalog is open.
Connect "logical" IO controller and IO devices
6. Connect the "logical" devices to each other by clicking on and holding the
port of the IO controller and dragging a connection on the port of the first
IO device.
7. Network the ports of all IO devices as described in 6.
Your PROFINET IO system is mapped to your TIA project.
1. Double click on the IO controller of your IO-System.
You will switch to the associated device view.
2. Click on the General tab > General > PROFINET interface > Ethernet
addresses in the device properties.
3. IP protocol section:
Use IP protocol Activate this option if not activated as the default.
Set IP address in the
project
If not active by default, activate this option and
change the IP and subnet addresses of the IO
controller.
1. Double click on the IO device of your IO system.
You will switch to the associated device view.
Define transfer volume
2. Hardware catalog: Click on Catalog > Module.
You have two categories available that define the general data volume
to be transferred.
3. Mark the required module and drag & drop it in the Device overview tab >
Module column.
The input and output addresses of the IO device are generated
automatically.
Assign device names
4. Device view: Double click on the IO device graphic.
5. Device properties: Click on the General tab.
6. General section:
Name Name the IO device according to the PROFINET
name conventions.
