ID 442710.00 20WE KEEP THINGS MOVING
Commissioning - SD6 and SIMATIC S7 with PROFINET
5
Operation manual PROFINET
7. [Optional] Section PROFINET interface > Ethernet addresses > IP
protocol:
Use IP protocol Activate this option if not activated as the default.
Set IP address in the
project
If not active by default, activate this option and
change the IP address of the IO device.
8. Device view: Mark the relevant IO device and right click on Assign device
name.
The Assign PROFINET device name window opens.
9. Click on Update list.
All IO devices of the defined subnet are listed together with the
specification of the respective device type as well as the associated IP
and MAC address.
10. Mark the IO device that you want to name and click on Assign name.
You can test your selection in advance by verifying the selected drive
controller via "Flash LED" or via its own MAC address (read A279 PN
MAC addresses parameter).
Configure IO cycle
11. Section Advanced options > Real-time settings > IO cycle > Update time:
Automatic If the time in which the controller and device
exchange IO-data should be automatically
calculated, activate this option.
Can be set If you want to calculate the update time yourself,
activate this option and specify the required time
(units: milliseconds).
Adapt update time
when send clock
changes
If the relationship between the update time and send
time should permanently remain constant, activate
this option.
12. Section Advanced options > Real-time settings > IO cycle > Response
monitoring time:
Accepted update
cycles without IO-
Data
Check the default setting and change the number of
permitted cycles without data transfer if necessary.
Response
monitoring time
The response monitoring time is automatically
calculated based on the accepted cycles; it must not
exceed 1.92 seconds.
13. Repeat steps 1 – 12 for each IO device of your PROFINET IO system.
