ID 442710.00 18WE KEEP THINGS MOVING
Commissioning - SD6 and SIMATIC S7 with PROFINET
5
Operation manual PROFINET
5.2.2 Install GSD
The functions and properties of the STOBER drive controllers are described in
the form of numerous objects and summarized in a GSD file.
To be able to map and configure the drive controller in the network, include this
STOBER-specific GSD file in the hardware catalog of your TIA project.
Requirement:
You have downloaded the GSD file from the STOBER download area and
saved it locally or copy it directly from the STOBER ELECTRONICS 6 CD
during the installation process.
5.2.3 Map PROFINET IO system
Map the IO controller of your PROFINET IO system as well as all drive
controllers, i.e. IO devices in a TIA project by selecting the relevant hardware
modules and including them in the project.
Requirement:
You have created a new project in TIA and installed the STOBER-specific
GSD. You are in the TIA network view; the hardware catalog is open.
1. Start the TIA Portal, create a project and save it. Open the TIA project
view.
2. Click on Options > General station description files (GSD).
The Manage general station description files (GSD) window opens.
3. Navigate to the directory that contains the STOBER-specific GSD and
click on OK.
The GSD is imported.
4. Set a check mark for the file and click on Install.
The GSD is installed; SD6 is integrated as a new IO device in the
hardware catalog.
Information
Note that you can only connect "logical" IO controllers and IO
devices in the TIA network view.
Include IO controller
1. Hardware catalog: Select Controller > SIMATIC S7-1500 > CPU and open
the folder of the CPU type that belongs to your controller (e.g.CPU 1513-
1 PN).
You obtain all article numbers of the selected CPU type.
2. Drag & drop the required CPU in the network view.
The IO controller is included in your project.
Include IO devices
3. Hardware catalog: Select Other field devices > PROFINET IO > Drives >
STÖBER ANTRIEBSTECHNIK GmbH & Co. KG > STOBER 6th
generation drives > PN6A.
4. Drag & drop the module in the network view.
The IO device is included in your project.
5. Repeat steps 3 and 4 for all IO devices that exist in your physical
PROFINET IO system.
