Operation manual PROFINET
6.4.1 Process data modules
An IO device generally includes head and process data modules that define the
data volume.
One of the following process data modules must be selected and assigned to
an IO device for the configuration in the TIA Portal.
"All consistent" means that the process data packet can only be processed
when the entire packet has been received.
"Items consistent" means that individual parameters from the packet are
processed when the parameter has been completely received.
We recommend the "all consistent" transfer type when creating a project.
Module Input 
data [byte]
Output 
data [byte]
Description
M101 02W PZD
all cons.
4 4 2 words (inputs, outputs), 
all consistent
M102 04W PZD
all cons.
8 8 4 words (inputs, outputs), 
all consistent
M103 06W PZD
all cons.
12 12 6 words (inputs, outputs), 
all consistent
M104 12W PZD
all cons.
24 24 12 words (inputs, outputs),
all consistent
M105 18W PZD
all cons.
36 36 18 words (inputs, outputs),
all consistent
M106 24W PZD
all cons.
48 48 24 words (inputs, outputs),
all consistent
M107 36W PZD
item cons.
72 72 36 words (inputs, outputs),
all consistent
M111 02W PZD
item cons.
4 4 2 words (inputs, outputs),
items consistent
M112 04W PZD
item cons.
8 8 4 words (inputs, outputs),
items consistent
M113 06W PZD
item cons.
12 12 6 words (inputs, outputs),
items consistent
M114 12W PZD
item cons.
24 24 12 words (inputs, outputs),
items consistent
M115 18W PZD
item cons.
36 36 18 words (inputs, outputs),
items consistent
M116 24W PZD
item cons.
48 48 24 words (inputs, outputs),
items consistent
M117 36W PZD
item cons.
72 72 36 words (inputs, outputs),
items consistent
