ID 442710.00 15WE KEEP THINGS MOVING
Commissioning - SD6 and SIMATIC S7 with PROFINET
5
Operation manual PROFINET
5.1.4.2 Adapt TxPZD
Requirement:
We recommend selecting an operation mode before this step and loading the
preassigned TxPZD via the associated "Fieldbus mapping" function in the list
of the data to be transferred.
2. You can transfer a maximum of 18 parameter values via RxPZD to the
drive controller.
Check the default settings and/or configure the process data according to
your requirements.
A90[0] – A90[5],
A91[0] – A91[5],
A92[0] – A92[5]
1st – 6th mapped
parameter
Parameter values that are transferred to the
controller.
The respective position (A90 – A92, 1st – 6th)
has information about the associated
transmission order.
Resulting length Total length of the data to be transferred. This must
not the exceed the value saved in the controller
(max. 72 byte). If necessary, change the type or
number of parameter values to be transferred.
Information
Note that the maximum total length of the parameters to be
transferred is configured in the controller.
1. Mark the relevant drive controller in the project tree and click in the Wizard
zone on the 1st projected axis > PROFINET TxPZD.
The PROFINET TxPZD wizard opens.
2. You can transfer a maximum of 18 parameter values via TxPZD to the
controller.
Check the default settings and/or configure the process data according to
your requirements.
A94[0] – A94[5],
A95[0] – A95[5],
A96[0] – A96[5]
1st – 6th mapped
parameter
Parameter values that are received by the controller.
The respective position (A94 – A96, 1st – 6th) has
information about the associated transmission order.
Resulting length Total length of the data to be transferred. This must
not the exceed the value saved in the controller
(max. 72 byte). If necessary, change the type or
number of parameter values to be transferred.
