ID 442710.00 36WE KEEP THINGS MOVING
More about PROFINET?
6
Operation manual PROFINET
LEDs – PN6
LEDs – RJ-45
LED- states in combination – Measures in the event of an error
State – RUN Meaning
On Connection to IO controller exists
Flash
(10 % on, 90 % off)
Connection to IO controller is being established
Flash, inverse
(90 % on, 10 % off)
IO controller activated DHCP-Signal-Service
Flashing Connection to IO controller exists; data transfer is
expected
Off No connection to IO controller
State – ERROR Meaning
On No network connection
Flashing at 2 Hz Data transfer inactive
Off Faultless state
State – Link Meaning
On Hardware connection to other bus subscribers
exists
Off No hardware connection to other bus subscribers
State – Act Meaning
Off No data transfer
Flashing Data traffic active; the flash speed indicates the
frequency of data exchange
LED Measure
Link = off • Check hardware connection to network
• Check infrastructure between SD6 and IO
controller
ERROR, Act and Link =
off
• Does the SD6 – IO controller connection exist?
• Is the drive controller correctly parameterized?
• Is the IO controller active and in RUN mode?
• Is the 100 Mbit Full Duplex link detected?
Act = off +
Link and ERROR = on
Check hardware connection
