STRUCTURE
Legend
1 Pillars (drive-in system)
2 Lifting arm (base frame)
3 Lifting cylinder: hydraulic cylinder for lifting and lowering
4 Upper support for the implement position indicator
5 Implement cylinders: hydraulic cylinders for dumping and scooping (differential cylinders)
6 Parking supports
7 Rating plate
8 Lever mechanism dumping/scooping
9 Euro change frame (implement support)
10 Implement locking mechanism
11 Cap for hydraulic and electrical distribution and additional equipment
12 Front loader locking mechanism
13 Coupling holder
14 Hydraulic couplings for the 3rd and 4th control circuit (optional)
15 Hydraulic and electrical distribution valves for additional equipment
16 Cross tube
17 Hydraulic tubes
18 Hydraulic hoses to the tractor (interface on the mounting part)
19 Connection cable (optional, multiple versions possible)
Sizes, see 11 Technical specifications.
