FUNCTIONS
4.9.3 Lowering throttle
⚠ WARNING
Possible material damage due to overloading!
The front loader can be lowered unevenly and be distorted when the two lowering throttles are not
adjusted in the same way, and can cause personal injury.
Set both lowering throttles to the same values.
The lowering throttle is used to set the lowering
speed of the front loader.
There is one lowering throttle on each side of the
lifting arm. Each lowering throttle is adjusted with
the rotary knob. There are numbers on the rotary
knob to enable more precise adjustment.
4.9.4 Camera system
NOTICE
Material damage due to loss of suction force!
Due to a natural loss of vacuum, the suction holder can lose suction force and fall off. This can damage
the camera system.
Detach the suction holder at regular intervals and fix it in place again.
NOTICE
Material damage due to adhesion!
If the suction holder is in contact with the window for too long, it can firmly adhere to the window and
damaged it.
Detach the suction holder at regular intervals and fix it in place again.
The camera system consists of a monitor, a camera and the corresponding cable sets.
It enables more precise work with the front loader and the mounted implements.
Observe the supplied documentation for the camera system.
Fig. 37 Lowering throttle
Legend
1 Rotary knob
