Web UI Header Diagram
1. Persistent Remote Control Bar
This area provides access to change some
settings without having to access the remote
control page. Change Source, Preset, Theater,
Proles within each theater, and Surround
modes.
2. Volume Control
Volume control is provided without having
to access the Remote Control page. The + / -
buttons adjust volume in 1dB increments. The
++/-- adjust volume in 3dB increments. Mute
cuts all sound. Dim attenuates the volume by
the amount specied in “Parameters” on page
28.
3. Conguration Section
• System: indicates information about the system
such as rmware version, any installed licenses,
network parameters. System conguration backups
and rmware updates are also done here.
• Inputs: Congure input names, map physical inputs
to source components, and make input dependent
settings.
• Main Speakers: Congure primary theater, child
theaters, audio/video and audio only zones. This is
where you map analog outputs to physical channels.
• Alternate Speakers: If the optional 16 channel
RCA/DB25 Output Card is installed, you will see an
Alternate Speakers tab to the right of Main Speakers.
Setup for the Alternate Speakers is identical to that
of Main Speakers.
• Settings: Congure trigger behavior, HDMI, IR, and
other system wide parameters.
• Presets: Build presets that easily recall combinations
of Theaters, downmix zones, EQ proles, triggers and
surround upmix behavior. Presets oer customers
the easiest way to place their system into modes for
dierent types of listening.
• Monitoring: This StormMonitoring page gives
real time and logged statistics on the health and
performance of the ISP which can be accessed via
the local network or via remote network access
which makes system diagnostic endeavors less
speculative and much more concrete.
• Remote Control: A copy of the page available to
anyone logging into the web UI regardless of their
credentials level. The only dierence between this
page and the one available without logging in is that
the Persistent Remote Control Bar remains at the
top.
4. Trigger / Generator / Power / Restart
• Trigger: Any triggers congured in Settings
(Conguration Section) for Manual Switching appear
here giving you easy access to activate or deactivate
these triggers with a click. Green indicates that the
trigger is in the active state. White indicates that it
is not.
• Generator: When white, the ISP built in noise
generator is not active. When green, it is active. This
is an indicator. The generator cannot be switched on
from here.
• Power: Switch the unit from standby to on status
from here. Green indicates that the unit is powered
on. White indicates standby.
• Restart: Should you need to restart the ISP, you can
do so from this switch.
1
2
3
4
5 6
