Contents
iii
Contents
Preface ix
1. Overview of ftServer 2600, 4500, and 6300 Systems 1-1
System Features 1-1
System Design 1-1
CPU-I⁄O Enclosures: Front 1-3
CPU-I/O Enclosures: Rear 1-5
Interior Components 1-6
Description of System Components 1-8
Peripheral Components 1-10
System CRUs 1-10
2. Hardware Operation 2-1
Standby Power 2-1
System Power 2-2
Starting Up the System 2-2
Shutting Down the System 2-3
Fan Speed 2-4
3. Troubleshooting the Hardware 3-1
Information About Troubleshooting 3-1
System Administration Documentation 3-2
Status LEDs and System Buttons 3-2
System Front Panel LEDs 3-4
CPU-I/O Enclosure Status LEDs 3-5
Memory Fault LEDs 3-8
Buttons on the CPU-I/O Enclosure 3-8
LEDs on the Back of the CPU-I/O Enclosure 3-9
Hard Disk Drive Status LEDs 3-10
Ethernet and VTM Port LEDs 3-12
Modem Assembly: Status LEDs 3-14
