Stratus ftServer 2600 - Figure 3-4. Ethernet and VTM Ports: Status Leds

Status LEDs and System Buttons
Troubleshooting the Hardware 3-13
Figure 3-4. Ethernet and VTM Ports: Status LEDs
Ta bl e 3- 5 describes the activity LED states for the Ethernet ports and VTM ports.
1 VTM port activity LED
2 VTM port connection speed LED
3 Green Ethernet port activity LED
4 Green or yellow Ethernet port connection speed LED
dco004b
12 34
4 3
