Removing and Replacing a CPU-I/O Enclosure
5-10 Stratus ftServer 2600, 4500, and 6300 Systems: Operation and Maintenance Guide (R639)
Figure 5-4. Loosening the Front Release Levers on an Enclosure
7. With one person supporting the enclosure on each side, pull it straight out until it is
stopped by the safety lever (number 1 in Figure 5-5) on its left side. Push down the
front end of the lever to disengage it.
1 Release levers (unlocked) (2) 3 Thumbscrews (2)
2 Positioning pins (2)
2
1
3
dco029c
