3.0 Connections
3.1 Connecting to TV & VCR
< Basic connection with a Scart cable >
1. Connect the satellite signal from the LNB to the LNB IN connector.
2. Connect the TV scart connector at the back of the receiver to the scart - in connector on your TV set.
FIGURE 4. Basic connection with a Scart cable
<Advanced connection of the receiver to the TV set and VCR>
1. Connect the satellite signal from the LNB to the LNB IN connector.
2. Connect the TV scart connector at the back of the receiver to the scart-in connector on your TV set.
3. Connect the VCR scart connector at the back of the receiver to the scart-in connector on your VCR.
FIGURE 5. Advanced connection of the receiver to the TV set and VCR
