Stryker MX-PRO R3 - Optional Three-Stage I.V. Pole Assembly - 6070-215-070

www.stryker.com 6082-209-001 REV A 91
Return To Table of Contents
Optional Three-Stage I.V. Pole Assembly - 6070-215-070
Item Part No. Part Name Qty.
A 1210-110-046 Back Up Ring 1
B 1210-110-047 Lock Ring 1
C 1210-110-049 Molded Actuator 1
D 6070-210-051 Base Tube 1
E 6070-110-051 Two-Stage Stage Slide Plug 1
F 6070-110-050 Hook Weldment 1
G 6070-115-030 Three-Stage Assembly (page 92) 1
H 6070-115-042 Two-Stage Stage Tube 1
I 6070-115-045 Bearing Plug 1
J 0026-005-000 Roll Pin 1
K 0026-006-000 Roll Pin 1
L 6070-110-012 I.V. Pole Pivot 1
Rev A
