Stryker Neptune 2 - Instructions for Use: Symbols; Symbol Definitions Glossary

0702-002-700 Rev-J EN
www.stryker.com 9
Symbol Definitions
VACUUM LIMIT
SETTING
MANIFOLD PORT FLUID SUCTION FILTER
COMPARTMENT
SMOKE FILTER COMPARTMENT FACILITY VACUUM
SOURCE PORTS
Instructions
Figure 4 To Prepare Rover for Collection
ON OFF 4L
4-LITER
20L
20-LITER
IV POLE
HEIGHT
ADJUST
VOLUME
RESET
EMPTY TANK STAND-BY
(FOR
VACUUM
SYSTEM)
SMOKE
EVACUATOR
