Zelzah - Multidimentional Phaser
pg 20
External Control – Configuring MultiSwitch Plus
Press either footswitch to exit and store the MIDI channel, the MIDI
OUTPUT setting, and the EXP/MIDI jack mode.
Turn the SPEED (4-STAGE) knob all the way counter-clockwise to
set the MIDI channel to Channel 1. The ON (4-STAGE) LED should
be GREEN.
Press and hold the ON (4-STAGE) footswitch while connecting
power to the pedal. Hold until both LEDs stop blinking.
Turn the MIX knob to select any of the following options:
Send MIDI CC, PC, and Other Data: WHITE
Send MIDI CC and Other Data: GREEN
Send MIDI PC and Other Data: PURPLE
Send Other Data: AMBER
Turn the SPEED (6-STAGE) knob all the way clockwise to set
the EXP/MIDI jack to MIDI mode. The ON (6-STAGE) LED should
be BLUE.
5
2
1
3
4
Configure Zelzah and MultiSwitch Plus for remote access to three
additional presets.
