Sealed System Information
Integrated
(700-
3
BASE)
Series
4-7
#3758424 - Revision B - December, 2005
Figure 4-3. Model 700BF/I-2 Refrigerant Flow
Compressor
Evaporator
Heater Loop
Heat Exchanger
Condenser
High-Side Filter Drier
