Airflow & Fan Blade Spacing
Integrated
(700-
3
BASE)
Series
5-3
#3758424 - Revision B - December, 2005
Figure 5-3. 700BF/I-3 Airflow and Fan Blade Spacing
11/16" ± 1/16"
(17.46 mm ± 1.59 mm)
Blade
Bracket
Clamp
Back
EVAPORATOR
FAN BLADE HUB
TO FAN BRACKET
SPACING
