Electrical Systems Operation & Diagnosis Module (602)
2008 Navigation Impreza
Note: 2009 Forester utilizes the same
type of system
NAVIGATION SCREEN STARTING UP
NAVIGATION SCREEN DISPLAYING SUBARU LOGO
The navigation system built by Kenwood
contains the display, controls, audio unit and
navigation computer. The system will display
the Subaru logo at each engine start and then
proceed to the start up screen.
RADIO WITHOUT NAVIGATION
AGREE SCREEN
The operation of the navigation system and the
info display is the same as past models. (Except
the controls are all located on the Navigation
unit.)
INFO DISPLAY MAIN SCREEN
025
026
027
028
029
