Electrical Systems Operation & Diagnosis Module (602)
Combination Meter
The Combination Meter receives CAN and Analog data. The CAN data is received from the LAN
while the Analog data is received directly from individual control modules or switches.
Examples of CAN and Analog Data:
CAN data Analog data
Fuel gauge Speedometer
Coolant temperature gauge Tachometer
Door open warning light Brake fluid level warning light
Front fog light indicator light Parking brake warning light
AWD warning light (Tire air pressure) ABS warning light
VDC warning light/VDC off indicator SRS airbag warning light
ATF temperature warning light Oil pressure warning light
Sport shift indicator (AT model) Charge warning light
Sport mode indicator (AT model) Check engine light
AT select level lever position Security/immobilizer indicator light
VDC operation light Head light beam indicator
Cruise control main switch indicator Lighting switch indicator
Cruise set indicator Turn signal indicator
Low fuel waning light Seat belt warning light
Rear fog light indicator*
VSP/ Speedometer
The vehicle speed signal provided as the input to the Combination Meter has CAN data and pulses
(analog data). Normally the pulse data input is used for the driving of the speedometer. The CAN
data is used as a backup when there is a problem with the analog data.
